FreeScan Combo Series

Multifunctional Metrology Laser 3D Scanner

  • Blue laser & Infrared light
  • Accuracy up to 0.02mm
  • Powerful and ergonomic
  • Reddot winner 2024

Compact and Powerful Metrology

Packs dual light sources in an ultra-compact shell, measuring just 193 x 63 x 53 mm. It's equipped with both blue laser and infrared VCSEL technology and weighs only 620g.
Metrology-grade Accuracy

Metrology-grade Accuracy

Accuracy up to 0.02mm, delivers consistent scanning results with high precision.
Versatile

Versatile Dual Light Scanning

An innovative combination of blue laser and infrared light sources meets the needs of diverse industrial 3D scanning scenarios.

Multiple Scanning Modes

Multiple Scanning Modes

Up to 25 cross laser lines to scan large objects quickly, 7 parallel laser lines to scan fine details, and a single laser line for deep hole and pocket area scanning.

Lightweight

Lightweight and Compact

The lightweight and ergonomic design of the Combo Series allows for use in a variety of narrow and complex environments.

Freescan_Combo

Blue Laser & Infrared Light

An innovative combination of blue laser and infrared light ensures accurate results in various scenarios, improving both efficiency and quality.

FreeScan Combo_Machenical_Parts_Scanning

Four 3D Scanning Modes to Cover All Types of Workpieces

  • Multiple-line mode with 26 or 50 laser lines for overall scans
  • Fine scanning mode with 7 parallel laser lines to acquire intricate details
  • Deep hole scanning mode with 1 single laser line
  • Infrared light mode for quick scans without markers
FreeScan_Combo

A Wise Choice for Metrology

The FreeScan Combo Series' laser scanning modes can achieve industrial-grade accuracy of up to 0.02 mm*, making it ideal for metrology applications.

*Based on VDI/VDE 2634, sphere-spacing error is assessed with traceable length artifacts and markers by measuring these at different locations and orientations within the working volume, in the accuracy lab certified with ISO/IEC 17025:2017 under environmental conditions: temperature 20 ± 0.5°C; humidity 40 ~ 60% RH.

FreeScan_Combo_high_speed_mode

Fast Scan Speed

It's multiple line mode projects up to 50 laser lines (FreeScan Combo + version) and scan at speeds of up to 3,600,000 points/sec

Powerful and Ergonomic

Powerful and Ergonomic

The FreeScan Combo Series boasts an ergonomic, compact, and lightweight design that makes 3D scanning convenient and easy.

The optimized camera angle makes it more suitable for working in narrow and complex environments, allowing for fast data capture in seams.

FreeScan Combo Infrared Light Scanning

Infrared Light Scanning

For feature-rich workpieces, the infrared light scanning mode is ideal. It captures parts quickly and efficiently without the need for markers.
Special Pricing for Reverse Engineering Bundle

Special Pricing for Reverse Engineering Bundle

Enhance your engineering and design capabilities with our professional reverse engineering bundle, featuring the FreeScan Combo Series 3D Scanner and EXModel. This combination offers precise and efficient solutions tailored for industries requiring detailed reproduction of objects into digital CAD models.







FreeScan Software

No subscriptions, no hidden fees.

SHINING 3D FreeScan Combo Series 3D Scanners come with access to our powerful and continuously updated software. Scan as much as you want, all year long, with no hidden fees or extra costs.

Step-by-step Guidance

Step-by-step Guidance

The FreeScan software will guide you through the 3D scanning process, from calibration to 3D scanning and data editing.

Multiple Scan Modes

Multiple Scan Modes

With FreeScan software, the Combo supports four kinds of scanning modes, providing users with the flexibility to choose according to their needs.

AI Data Cleanup

AI Data Cleanup

FreeScan software is equipped with intelligent algorithms that can process and optimize scanning data more efficiently, delivering more ideal results.

Adjustable Resolution

Adjustable Resolution

FreeScan software can select corresponding solutions based on different scanned samples, making it more flexible in meeting various scanning requirements.

Technical Data

  • High-speed Scanning 50 or 26 laser lines
  • Detailed Scan 7 laser lines
  • Deep Pockets 1 single line
  • No Markers Scan Infrared mode
  • Accuracy Up to 0.02 mm
  • Max. FOV 520 × 510 mm / 600 × 600 mm
  • Volumetric Accuracy 0.02 + 0.033 mm/m
  • Point Distance 0.05 ~ 10 mm / 0.1 ~ 3 mm
  • Scan Speed Up to 3,600,000 points/s
  • Weight 620g
  • Certifications CE, FCC, ROHS, WEEE, KC, FDA, UKCA, IP50, TISAX
  • Accuracy Certification VDl/VDE 2634 Part 3 (ISO 17025 certificated lab)

Global Brands Trust Us

20

years of experience

400

patents

100

3D scanners sold Worldwide

  • Vision Miner

    The FreeScan Combo's ability to handle reflective surfaces and its flexibility in adjusting to various scanning angles makes it an exciting choice for serious and accurate 3D scanning projects.



    Robert Lent,

    Chief Operating Officer, Vision Miner



Frequently Asked Questions

  • Is it possible to scan without applying markers on object?

    Yes. FreeScan Combo is a dual light source scanner, and the infrared light source can be used to quickly scan feature-rich workpieces without the need for markers on the surface.
  • Is it possible to scan color texture of objects?

    No. FreeScan Combo doesn't have a color camera to capture the texture information of object.
  • How can I scan a deep hole?

    FreeScan Combo offers four scanning modes to choose from. Use one single blue laser line to obtain deep-hole data.
  • When do I need to calibrate the 3D scanner?

    1. When using for the first time or after 1-2 weeks of inactivity.

    2. If the scanner has been severely shaken or vibrated, like during transport.

    3. If accuracy is significantly reduced, causing frequent alignment errors or unrecognized markers.

    4. If scanning data is incomplete or the quality has seriously deteriorated.

  • Can FreeScan Combo scan black or reflective object?

    Yes, FreeScan Combo is equipped with blue laser source, which has a very strong adaptability of black and reflective surface.
  • Can I use FreeScan Combo to scan human body?

    Yes. Infrared light source scanning can be used to scan human boady.
